(Single-tube Packing Seal) Tubular Type Graphite Heat Exchanger

LGH type Graphite Tubular Heat Exchanger
LGH type Graphite Tubular Heat Exchanger
LGH type Graphite Tubular Heat Exchanger
LGH type Graphite Tubular Heat Exchanger
LGH type Graphite Tubular Heat Exchanger

(Single-tube Packing Seal) Tubular Type Graphite Heat Exchanger

The tubular graphite heat exchanger is a type of heat transfer equipment fabricated from graphite. It exhibits excellent corrosion resistance and is extensively utilized in industries such as chemical and petrochemical for highly efficient heat exchange processes.

  • 支付:

    TT L/C PayPal Westunion Moneygram

  • 产品起源:

    China， Anhui province

  • 颜色:

    customized

  • 运输端口:

    shanghai

  • 交货时间：

    1 month

  • 量:

    1

  • 包裹:

    wooden case

  • 颜色:

    white

  • 材料:

    graphite

  • 工作温度:

    ≤170℃

  • 工作压力:

    ≤0.7MPa
现在询问
Graphite Condenser circular Block Type Graphite Heat Exchanger graphite Cooler

Product review

Typically, the equipment is assembled with Φ22/Φ32 mm extruded graphite tubes. Moreover, graphite tubes with diameters of Φ25/Φ37 mm and Φ36/Φ50 mm can also be produced.



Graphite Condenser circular Block Type Graphite Heat Exchanger graphite Cooler

Product advantages

The LGH type features a single-tube packing seal type shell and tube structure, which enables it to withstand high operating temperatures and allows for rapid heating from 20°C up to 150°C.





Structural diagram



Graphite Condenser circular Block Type Graphite Heat Exchanger graphite Cooler



Parts details
1 Upper cover plate
2 Graphite upper head
3 Graphite upper tube sheet
4 Vent
5 Outlet
6 Graphite baffle
7 Graphite heat exchange tube
8 Equipment support
9 Equipment shell
10 Intake
11 Graphite lower tubesheet
12 Drain port
13 Graphite lower head
14 Q235 lower cover plate



Drawing Specification Table



Model Specifications Heat exchange tube Installationdimension  mm Weight
M Inside diameter Outer diameter Quantity D H H1 H2 H3 d1 d2 n1-M1 L1 L2 n2-Φ2 kg
GGH50 15 22 32 61 550 3580 2000 431 371 150 240 8-M20 792 872 2-Φ24B2 700
GGH50 20 22 32 61 550 4580 2800 431 371 150 240 8-M20 792 872 2-Φ24B2 800
GGH55 20 22 32 73 550 3890 2000 441 371 150 240 8-M20 843 923 2-Φ24B2 850
GGH55 25 22 32 73 550 4590 2800 441 371 150 240 8-M20 843 923 2-Φ24B2 900
GGH60 25 22 32 91 610 3644 2000 494 404 200 295 8-M20 904 984 4-Φ24B2 950
GGH60 30 22 32 91 610 4644 2800 494 404 200 295 8-M20 904 984 4-Φ24B2 1100
GGH65 30 22 32 109 650 3684 2000 514 424 200 295 8-M20 944 1024 4-Φ24B2 1350
GGH65 40 22 32 109 650 4684 2800 514 424 200 295 8-M20 944 1024 4-Φ24B2 1550
GGH65 45 22 32 109 650 5684 3500 514 424 200 295 8-M20 944 1024 4-Φ24B2 1750
GGH70 35 22 32 127 710 3728 2000 556 456 250 350 12-M20 1040 1140 4-Φ30B3 1450
GGH70 45 22 32 127 710 4728 2800 556 456 250 350 12-M20 1040 1140 4-Φ30B3 1700
GGH70 55 22 32 127 710 5728 3500 556 456 250 350 12-M20 1040 1140 4-Φ30B3 1950
GGH75 40 22 32 151 740 3768 2000 576 476 250 350 12-M20 1070 1170 4-Φ30B3 1650
GGH75 50 22 32 151 740 4768 2800 576 476 250 350 12-M20 1070 1170 4-Φ30B3 1900
GGH75 65 22 32 151 740 5768 3500 576 476 250 350 12-M20 1070 1170 4-Φ30B3 2150
GGH80 45 22 32 175 810 3812 2200 618 518 250 350 12-M20 1141 1241 4-Φ30B3 2000
GGH80 60 22 32 175 810 4812 3000 618 518 250 350 12-M20 1141 1241 4-Φ30B3 2300
GGH80 75 22 32 175 810 5812 3600 618 518 250 350 12-M20 1141 1241 4-Φ30B3 2600
GGH85 50 22 32 199 850 3852 2200 638 538 250 350 12-M20 1181 1281 4-Φ30B3 2200
GGH85 70 22 32 199 850 4852 3000 638 538 250 350 12-M20 1181 1281 4-Φ30B3 2500
GGH85 85 22 32 199 850 5852 3600 638 538 250 350 12-M20 1181 1281 4-Φ30B3 2800
GGH90 55 22 32 223 900 3896 2400 662 562 300 400 12-M20 1232 1332 4-Φ30B3 2450
GGH90 75 22 32 223 900 4896 3000 662 562 300 400 12-M20 1232 1332 4-Φ30B3 2800
GGH90 95 22 32 223 900 5896 3600 662 562 300 400 12-M20 1232 1332 4-Φ30B3 3150
GGH95 65 22 32 253 950 3936 2400 682 582 300 400 400 1282 1382 4-Φ30B3 2750
GGH95 85 22 32 253 950 4936 3000 682 582 300 400 400 1282 1382 4-Φ30B3 3150
GGH95 110 22 32 253 950 5936 3600 682 582 300 400 400 1282 1382 4-Φ30B3 3550
GGH100 70 22 32 271 1000 3990 2500 738 638 300 400 400 1462 1602 4-Φ30B4 3250
GGH100 90 22 32 271 1000 4990 3000 738 638 300 400 400 1462 1602 4-Φ30B4 3700
GGH100 115 22 32 271 1000 5990 3600 738 638 300 400 400 1462 1602 4-Φ30B4 4150
GGH100 140 22 32 271 1000 6990 4600 738 638 300 400 400 1462 1602 4-Φ30B4 4600



Energy-saving Graphite Condenser Tubular Heat Exchanger



Tube Specification Table

Model a b c d e f
GGH50 150 1/4" 65 150 1/4" 65
GGH55 150 1/4" 65 150 1/4" 65
GGH60 200 1/4" 80 200 1/4" 80
GGH65 200 1/4" 80 200 1/4" 80
GGH70 250 1/4" 100 250 1/4" 100
GGH75 250 1/4" 100 250 1/4" 100
GGH80 250 1/4" 125 250 1/4" 125
GGH85 250 1/4" 125 250 1/4" 125
GGH90 300 1/4" 125 300 1/4" 125
GGH95 300 1/4" 125 300 1/4" 125
GGH100 300 1/4" 150 300 1/4" 150
Connection standard Non-standard / HG20593 PNO.6 Non-standard / HG20593 PNO.6
Uses Material import Exhaust port Steam inlet Material export Exhaust port Condensate outlet
